ABB INVERTER ,ACS550 read more

            ABB Standard Drive รุ่น ACS550 ใช้งานได้ทั่วไป สามารถใช้ในหลากหลายอุตสาหกรรม
รวมถึงปั๊มพัดลมและการใช้แรงบิดอย่างต่อเนื่อง เช่นสายพาน ACS550, 0.75 to 355 kW/1 to 500 hp

คุณสมบัติ :

- Power range: 0.75 to 75 kW (0.8 to 100 hp), 0.75 to 160 kW (0.5 to 200 hp)
- Supply voltage 3-phase, 208 to 240 V +10% /-15%, 3-phase, 380 to 480 V +10% /-15%

ACS550 – general purpose drive
All your energy saving options covered from the start

When you need simplicity and intelligence in one self-contained solution the ACS550 covers a wide range of options. Ideal for variable and constant torque applications from pumps and fans to conveyors and mixers as well as many other variable and constant torque applications. Enjoy plug and play convenience right from the start. No customizing or special product engineering required.  Monitor your savings easily with the built-in counters, which display energy savings in kilowatt hours, carbon dioxide emissions or local currencies.

Highlights

0.75 to 355 kW/1 to 500 Hp
Vector control
Built-in EMC filter and Modbus fieldbus interface
Swinging choke for superior harmonic reduction
Coated boards for harsh environments
Power range:
0.75 to 75 kW (0.8 to 100 hp)
0.75 to 160 kW (0.5 to 200 hp)

Supply voltage:
3-phase, 208 to 240 V +10% /-15%
3-phase, 380 to 480 V +10% /-15%
ABB general purpose drives can be used in a wide range of industries. Typical applications include pump, fan and constant torque use, such as conveyors. ABB general purpose drives are ideal in those situations where there is a need for simplicity to install, commission and use and where customizing or special product engineering is not required. The drives include several features as standard, such as swinging choke, EMC filter and control panel. All drives are tested with full load at the factory ensuring premium quality. To view technical data of the products, please click on the Data tab above.

Highlights
− Energy efficiency counters
− Intuitive use with assistant control panel
− Swinging choke for superior harmonic reduction
− Vector control
− Coated boards for harsh environments
− Built-in category C2 EMC filter (1st environment) as standard
− Flexible fieldbus system with builtin Modbus and numerous internally mountable fieldbus adapters
− Brake chopper as standard in the frames R1 and R2
− FlashDrop tool for cold configuration
